Specifications: Specifications:
> Optimal placement rate 72,000 cph
> Applicable Components 0402(Metric base) to 32 x 32mm, Max Height 6.5mm
> Mounting accuracy:(x,y) 3σ Absolute accuracy (μ+3σ) : +/-0.05mm/CHIP(QFP) Repeatability (3σ) : +/-0.03mm/CHIP(QFP)
> Applicable PCB (mm) L50 x W50 to L700 x W460 PCB Thickness(mm) 0.3 –4.5
> Applicable components 0402(Metric base) to 32 x 32mm, Max Height 6.5mm
> Number of component types Tape reel : 120 types (Fixed plates, Max., 8mm width) Tape reel : 96 types (FES Carts, Max., 8mm width)
> Types of Feeders 96 x 8mm
> Number of Head & Nozzle 20
